With porous resin moulds, high pressure casting delivers 20 or more products per shift from a single mould where traditional plaster casting allows only one or two. With proper coordination of mould design and slip formulation, CASTIMO moulds achieve over 100,000 casting cycles. All resins ship as 4-5 component systems with long processing times and high pressure resistance.
Open-pore microstructure the basis for uniform water drainage.
The business case
Castimo offers four and five component porous resin systems in FINE PORE, MICRO and PRO versions. Each system is selected according to application, mould size and production requirements for optimal performance in high-pressure casting processes.
The finest pore structure in the range for delicate surfaces and fine slip formulations where surface quality takes priority over cycle speed. The extended processing time allows complex mould geometries to be cast without defects.
Small pore structure of 12–15 microns, designed for fine slip parts the tight structure reduces pore clogging and keeps casting behaviour stable over the mould’s lifetime.
Medium to large pore structure of 16–19 microns for maximum drainage delivering products around 25 % faster than the MICRO version where slip formulation allows it.
Related
Castimo offers customer-specific pore structures and customer-specific product production matched to your slip, your products and your casting process.
Tell us about your products, slip and casting process we recommend the right FINE PORE,MICRO or PRO system and configuration.
Engineering, equipment, moulds, installation, commissioning and ramp-up one contract, one responsibility, one contact person. From the first feasibility study to stable series production.
Project phases
High-porosity resin systems for High Pressure Slip Casting over 100,000 casting cycles per mould.
Systems & products
Cleaning, care and mould paints for maximum mould lifetime and consistent casting results.
Systems & products
RECKLI products for model and mould production clean mould release and flawless plaster moulds with fast setting and long service life.
Systems & products
From model development to serial moulds our own mould shop, not a subcontractor.
Systems & products
Slip and glaze preparation, storage, screening and weighing the basis for constant casting quality.
Systems & products
Traditional bench casting and high pressure casting machines of the ANKA series dimensioned to your output.
Systems & products
A smart drying solution with digital process integration uniform, optimised drying that minimises cracking, warping and surface imperfections.
Systems & products
Glaze application, retouching, foot wiping and syphon glazing from manual cabins to carousel lines.
Systems & products
Firing is integrated into the overall layout to ensure smooth material flow and compatibility with the defined production concept kiln type, capacity and kiln-car concept are dimensioned to the casting output.
Systems & products
Casting, glazing and logistic robots added where they pay off, not everywhere.
Systems & products
Transport and conveyor systems connecting every stage of the line.
Systems & products
Feasibility, capacity concept and factory layout the earlier we are involved, the more efficient your plant becomes.
Systems & products
Laboratory equipment and functional testing for running production.
Systems & products
Overhauled machines where the budget decides available equipment changes continuously, information on request.
Systems & products
Spare parts, modernization and training after handover.
Systems & products
